User manuals

Making things simple isn’t always easy!

For your manual, select an image of the antenna you have, which can be found below the ‘Current Sales’.

MANUALS

100W MagLoop

Portable 100W HF (10-40M MagLoop

Options include the ability to add VHF/UHF/6M with a second option to add a 40/80M Booster Cable

EmComm Loop

Portable VHF/UHF/HF (15-40M) EmComm Loop rated at 100W PEP

Base Loop

Remotely controlled 10-40 meter base and transportable Alpha Loop for indoor or permanent outdoor base deployments.

Digital HF MiniLoop

Digital Broadband MiniLoop Antenna that provides 0-2500km coverage on 10MHz through 54MHz.

HexTenna

The HexTenna™ by Alpha Antenna® is a legal limit and full size portable VHF/UHF/HF system for 2 to 40 meters, 220MHz, & 440MHz.

EmComm (FMJ/MIL/TAC)

The Alpha EmComm systems require no moving clips on coils or readjusting of whips for tuning.

HF Base LT Antenna

10-80 meter multiband system Off-Center Fan/Fed Vertical Antenna that is rated at 250W PEP.

JPole Jr

The unique design characteristics of this 6-80 Meter HF JPole antenna enables it to approach resonance on the major HF bands (6/10/12/15/17/20/40/80 Meters), all of which presents an SWR that is low enough for external tuners to achieve a near perfect match.

HF Base HD Antenna

The HF Base HD Antenna provides a balanced limited space (permanent base or transportable) system, which maximizes effective radiated power (ERP) while maintaining a SWR on 10-80 meters and Marine HF bands of less than 2.5:1, and *160 meters with optionally available “four 35 foot wire elements”.

JPole Sr

The unique design characteristics of this 10-160 Meter HF JPole antenna enables it to approach resonance on the major HF bands (/20/40/80 Meters), all of which presents an SWR that is low enough for external tuners to achieve a near perfect match, including 160 meters.

HOA Buster

Defeat HOAs with this HF antenna, which presents an SWR that is low enough for external tuners to achieve a near perfect match.

HF Moto

The Alpha MOTO-FMJ (Full Metal Jacket) provides you with the most Rugged and Compact HF mobile EMCOMM antenna system available.

Enhancement Kit (EK-705)

Enhancement Kit for the ICOM AL-705 magnetic loop antenna. Power ratings with the Booster Cable are 10 watts on PEP SSB and 5 watts CW, AM, FM, & Digital modes.

Tripod Mount (TM-705)

This Tripod Mount (TM-705) for the Icom AL-705 antenna will fit on any tripod with a 1/4 20 male thread. On the other side are two screws that fit into the tabs, which came with your antenna, that you must first install on the tuning box of the AL-705.

Rig Mount (RM-705)

The Rig Mount (RM-705), which screws on top of tripod’s male 1/4 20 thread, is for mounting the ICOM IC-705 transceiver and AL-705 magnetic loop antenna on a tripod.
